CooliBlade ULTIMA

Lightweight and powerful platform
for cooling of IGBT and renewable energy.

ULTIMA Evaluation Designs

ULTIMA

CooliBlade ULTIMA is a potent and adaptable forced convection cooling solution. Its unique design offers extensive installation flexibility, lightweight structure, and powerful cooling abilities.

Power levels

Up to 2 500 W/ unit.

Thermal resistance

0.028 K/W

Use case

Power modules

Features

Powerful cooling up to kilowatts
Integrated evaporator, thermal channel and condenser
Low prototype investment
Horizontal and vertical installations possible

Applications

Industrial control, AC drives, IGBT, renewable energy, power inverters/converters

Product Options

ULTIMA Horizontal Evaluation Design

The easiest way to evaluate the ULTIMA performance is to check our evaluation designs. This is ULTIMA for horizontal installations. You can select from our standard module mountings or send your own lay-out  for mounting drillings.

ULTIMA Vertical Evaluation Design

The easiest way to evaluate the ULTIMA performance is to check our evaluation designs. This is ULTIMA for vertical installations. You can select from our standard module mountings or send your own lay-out  for mounting drillings.
COMING SOON.

OEM Heat Sink Development

A custom design for heat sink is usually necessary when cooling high-power electronics. Through rapid prototyping, we build a prototype for your product design and transfer it into OEM Heat Sink production quickly.

ULTIMA Benefits

Powerful

ULTIMA is designed to handle power levels up to several kilowatts per module, making it a powerful solution for industrial power electronics applications. Its superior efficiency is achieved through the integration of a large evaporator and optimized fin structure.

Lightweight

With its construction of aluminum pipes and thin sheet metal fins, ULTIMA is exceptionally lightweight. This facilitates easier design and integration processes for the customer’s end product.

Optimized product design integration

ULTIMA’s fin design has been optimized to offer high airflow and minimal back pressure, ensuring effective forced convection cooling.

Installation freedom

ULTIMA provides engineers with the freedom to innovate in product design due to its versatile installation capabilities. Available in two alternative models, ULTIMA can be installed both horizontally and vertically, offering adaptability to a wide variety of design requirements.

Applications

CooliBlade ULTIMA is efficient cooling technology for high power electronics modules, such like IGBTs. IGBT modules (Insulated-gate bipolar transistor) are typically used e.g., in AC drives and EV mobility charging stations. IGBT modules are one of the most demanding components for thermal management. NEOcore technology enables the lowest thermal resistance from the IGBT to ambient.

Industrial

Energy

Interested in ULTIMA?

Familiarize yourself with the help of a ULTIMA product sheet.

Read the product brochure

What are the specifications behind the ULTIMA series?

We compiled the technical specifications and measurements of the ULTIMA for you.

Download the Data Sheet
